As a direct factory-exporter of FRP pipes in China, we specialize in engineering heavy-wall, high-temperature-resistant piping systems for power plant flue gas desulfurization (FGD) and geothermal energy extraction projects—environments where traditional carbon steel fails within months. Our production capabilities extend to DN4000 large-diameter jacking pipes with proprietary bell-and-spigot joints, specifically designed for trenchless microtunneling in urban municipal works. We operate a fully digitalized winding line that allows rapid mold changes, enabling us to accommodate custom pressure ratings (PN10 to PN25) and custom lay-up angles without minimum order quantity penalties. Critically, as a registered export entity with 8+ years of letter-of-credit and D/P settlement experience, we provide consolidated container loading plans, fumigation-free export crates, and full material traceability from ISO-tank resin delivery to final hydrostatic testing—ensuring your site receives project-matched components, not off-the-shelf generics, with lead times 20% shorter than Southeast Asian competitors.
Brochão de Produtos da Hebei Fortis Technology Co., Ltd
Product Advantages
1. Unmatched Corrosion Resistance for Harsh Chemical Environments
Unlike carbon steel or cast iron, our FRP pipes are inherently inert to a wide spectrum of corrosive agents—including sulfuric acid, hydrochloric acid, alkaline slurries, and saltwater. The thermosetting resin matrix (available in orthophthalic, isophthalic, vinyl ester, or epoxy formulations) acts as a permanent barrier against electrochemical and microbiologically induced corrosion (MIC). This eliminates the need for expensive internal linings, cathodic protection, or frequent recoating, making our pipes the preferred choice for chemical dosing lines, effluent treatment, and coastal seawater intake systems where metal alloys would fail within months.
2. Exceptional Strength-to-Weight Ratio Simplifying Logistics and Installation
Our filament-wound FRP pipes offer a specific strength that rivals or exceeds carbon steel, yet they weigh only 1/5 to 1/4 of steel pipe of the same diameter and pressure rating. This lightweight characteristic dramatically reduces transportation costs, allows for longer single-piece lengths (up to 12 meters or custom), and minimizes the need for heavy lifting equipment during site installation. For offshore platforms, mountainous terrains, or congested plant retrofits, this lower deadweight translates to faster crew handling, smaller foundation supports, and significant savings on crane hire and rigging time.
3. Superior Hydraulic Performance with Sustained Flow Efficiency
The internal bore of our FRP pipes is manufactured with a smooth, non-porous surface finish (Hazen-Williams coefficient C = 150, versus 120–130 for steel or concrete). This ultra-low friction coefficient minimizes pumping energy requirements over the entire system lifecycle. More critically, our pipes are absolutely immune to scale buildup, tuberculation, or biofilm adhesion—common issues that progressively choke metallic and concrete pipelines. As a result, your flow rates remain constant at design capacity even after 10+ years of service, cutting electricity consumption for pumps by 15–25% compared to aging steel systems.
Parameter Specifications
|
Product |
FRP pipe |
||||
|
|
|||||
|
Model |
Inner.dia(mm) |
Length(mm) |
Channel Thickness(mm) |
||
|
P=0.6Mpa |
P=1.0Mpa |
P=1.6Mpa |
|||
|
FT-Pp10 |
10 |
1800 |
4.6 |
4.6 |
4.6 |
|
FT-Pp15 |
15 |
||||
|
FT-Pp20 |
20 |
||||
|
FT-Pp25 |
25 |
||||
|
FT-Pp32 |
32 |
||||
|
FT-Pp40 |
40 |
||||
|
FT-Pp50 |
50 |
6000 |
|||
|
FT-Pp65 |
65 |
||||
|
FT-Pp80 |
80 |
||||
|
FT-Pp100 |
100 |
5.9 |
|||
|
FT-Pp125 |
125 |
||||
|
FT-Pp150 |
150 |
5.9 |
|||
|
FT-Pp200 |
200 |
5.9 |
7.2 |
||
|
FT-Pp250 |
250 |
12000 |
8.5 |
||
|
FT-Pp300 |
300 |
7.2 |
9.8 |
||
|
FT-Pp350 |
350 |
8.5 |
11.1 |
||
|
FT-Pp400 |
400 |
12.4 |
|||
|
FT-Pp450 |
450 |
7.2 |
9.8 |
13.7 |
|
|
FT-Pp500 |
500 |
||||
|
FT-Pp600 |
600 |
8.5 |
12.4 |
15.0 |
|
|
FT-Pp700 |
700 |
9.8 |
13.7 |
20.2 |
|
|
FT-Pp800 |
800 |
15.0 |
22.8 |
||
|
FT-Pp900 |
900 |
11.1 |
16.3 |
25.4 |
|
|
FT-Pp1000 |
1000 |
12.4 |
17.3 |
28.0 |
|
|
FT-Pp1200 |
1200 |
13.7 |
|
|
|
|
FT-Pp1400 |
1400 |
16.3 |
|
|
|
|
FT-Pp1500 |
1500 |
|
|
||
|
FT-Pp1600 |
1600 |
17.6 |
|
|
|
|
FT-Pp1800 |
1800 |
18.9 |
|
|
|
|
FT-Pp2100 |
2100 |
22.8 |
|
|
|
|
FT-Pp2400 |
2400 |
25.4 |
|
|
|
|
FT-Pp2600 |
2600 |
26.7 |
|
|
|
|
FT-Pp3000 |
3000 |
30.6 |
|
|
|
|
FT-Pp3300 |
3300 |
33.2 |
|
|
|
|
FT-Pp3600 |
3600 |
35.8 |
|
|
|
|
FT-Pp4000 |
4000 |
39.7 |
|
|
|
