FRP Horizontal Storage Tanks Exporters – Chemical Water & Oil Sites FT-HST18a

This page serves global buyers seeking durable, corrosion-proof FRP horizontal storage tanks for critical applications including chemical reagent holding, municipal wastewater equalization, and diesel/gasoline bulk fuel farms. As a China-based export supplier, we combine ISO-certified helical filament-winding and hand lay-up processes to produce tanks from 1m³ to 150m³, with optional secondary containment, UV-resistant gelcoat, and flanged nozzles per ASTM D3299. Our advantage lies in short production cycles (15–25 days), flexible customization for ASME or local pressure specs, and consolidated sea freight logistics to the Middle East, Southeast Asia, Africa, and South America. Every tank undergoes 100% hydrostatic and spark testing before shipment, ensuring zero leakage and 20+ years of service life in aggressive soil or above-ground conditions.

Brochão de Produtos da Hebei Fortis Technology Co., Ltd

Baixar

Consulte agora Próximo Produto

Product Advantages Parameter Specifications

Product Advantages

Superior Corrosion Resistance for Aggressive Media
Our FRP horizontal tanks are engineered with isophthalic or vinyl ester resins specifically selected to withstand highly corrosive contents—including sulfuric acid, sodium hypochlorite, ferric chloride, and crude oil brines. Unlike carbon steel or stainless steel, FRP does not pit or rust, even in continuous immersion or high-humidity environments. This chemical inertness ensures your stored medium remains uncontaminated, extending both tank life and process reliability.

Exceptional Strength-to-Weight Ratio Reducing Installation Costs
Weighing approximately 75% less than equivalent steel tanks, our horizontal FRP vessels significantly lower crane, foundation, and transportation expenses. The lightweight construction allows for easier maneuvering into tight plant layouts or remote job sites without heavy lifting equipment. Despite this low weight, the helical filament-winding process delivers high hoop and axial strength, enabling burial depths of up to 1.5 meters or above-ground span support with minimal deflection.

Customizable Design for Site-Specific Requirements
Every project receives a tailor-made solution. We customize diameters (up to 4 meters), lengths, wall thicknesses, nozzle positions, flanges (ANSI/DIN/JIS), and internals such as baffles, heating coils, or agitation rings. Optional secondary containment (double-wall) meets EPA spill prevention requirements, while UV-resistant gelcoats and anti-static conductive liners are available for flammable fuels or outdoor installations in tropical/desert climates.

Parameter Specifications

Product	Horizontal Storage Tank
F=D/4
Model	Volume(m³)	Diameter(mm)	Height(mm)	Number of Supports N1
FT-HST1	1	1000	1450	2
FT-HST2a	2	1000	2730	3
FT-HST2b	2	1200	1990	2
FT-HST2c	2	1400	1560	2
FT-HST3a	3	1000	4010	4
FT-HST3b	3	1200	2870	2
FT-HST3c	3	1400	2200	2
FT-HST4a	4	1200	3760	3
FT-HST4b	4	1400	2850	3
FT-HST5	5	1400	3500	3
FT-HST6	6	1600	3300	2
FT-HST7	7	1600	3800	3
FT-HST8a	8	1600	4300	3
FT-HST9	9	1600	4780	3
FT-HST10a	10	1600	5300	3
FT-HST10b	10	2000	4250	3
FT-HST11a	11	1600	5800	4
FT-HST11b	11	2000	4640	3
FT-HST12a	12	1600	6280	4
FT-HST12b	12	2000	5040	3
FT-HST12c	12	2200	3540	2
FT-HST15a	15	2000	6220	3
FT-HST15b	15	2200	4330	2
FT-HST15c	15	2400	3750	2
FT-HST18a	18	2000	7400	4
FT-HST18b	18	2200	5120	2
FT-HST18c	18	2400	4410	2
FT-HST20a	20	2000	8190	4
FT-HST20b	20	2200	5650	3
FT-HST20c	20	2400	4850	2
FT-HST20d	20	2600	4220	2
FT-HST25a	25	2000	8310	4
FT-HST25b	25	2200	6960	3
FT-HST25c	25	2400	5960	2
FT-HST25d	25	2600	5160	2
FT-HST25e	25	2800	3740	2
FT-HST30a	30	2200	8280	4
FT-HST30b	30	2400	7060	3
FT-HST30c	30	2600	6100	3
FT-HST30d	30	2800	4560	2
FT-HST30e	30	3000	4100	2
FT-HST35a	35	2400	8170	3
FT-HST35b	35	2600	7050	3
FT-HST35c	35	2800	5370	2
FT-HST35d	35	3000	4820	2
FT-HST40a	40	2400	9270	3
FT-HST40b	40	2600	7990	3
FT-HST40c	40	2800	6180	2
FT-HST40d	40	3000	5520	2
FT-HST50a	50	2600	9870	4
FT-HST50b	50	2800	6990	2
FT-HST50c	50	3000	6240	3
FT-HST60a	60	2800	8620	3
FT-HST60b	60	3000	7660	3
FT-HST70a	70	2800	10240	3
FT-HST70b	70	3000	9050	3
FT-HST80a	80	3000	10470	4
FT-HST80b	80	3000	11880	4
